The compact twin-stage regulator is designed to reduce container
pressure down to 11” w.c. delivery pressure. It is ideal for “on site”
container applications such as homes, mobile homes and cottages
for average domestic service; including small ASME tanks and
100-420 pound DOT cylinders.
Info
|
Part Number |
Inlet Connection |
Outlet Connection |
Orifice Size |
Factory Delivery Pressure |
Adjustment Range 2nd Stage |
Bonnet Vent Position 1st Stage** |
Bonnet Vent Position 2nd stage** |
Vapor Capacity BTU/hr* |
| LV404B34 | ¼" F.NPT | ½" F.NPT | .100 | 11" w.c. @ 100 Psig Inlet | 9" to 13"w..c. | Rear | Outlet | 450,000 |
| LV404B39 | F.POL | |||||||
| LV404B34V9 | ¼" F.NPT | Left | 9:00 | |||||
| LV404B39V9 | F.POL |
* Maximum flow based on 10 PSIG Inlet 9” w.c. delivery pressure
** Other vent positions available upon request
