Info
Designed to reduce first stage pressure of 5 to 20 PSIG down to
burner pressure,normally 11” w.c. Ideal for larger commercial and
industrial applications, multiple cylinder installations and large
domestic systems.
| Part Number | Inlet Connection | Outlet Connection | Orifice Size | Factory Delivery Pressure | Adjustment Range | Bonnet Vent Position | Vapor Capacity BTU/hr. Propane |
| LV5503B4 | ½" F. NPT | ¾" F. NPT | ¼" | 11" w.c. at 10 PSIG Inlet |
9" - 13" w.c. | Over Inlet | 1,600,000 |
| LV5503B6 | ¾" F. NPT | ||||||
| LV5503B8 | 1" F. NPT | 9/32" | 2,300,000 |
Maximum flow is based on 10 PSIG inlet and 9” w.c. delivery pressure.
