Info:
Provides accurate first stage regulation in two-stage bulk tank
systems. Reduce tank pressure to an intermediate pressure of 5 to 10
PSIG. Also used to supply high pressure burners for applications like
industrial furnaces or boilers. Also incorporated in multiple cylinder
installations.
| Part Number | Inlet Connection | Outlet Connection | Orifice Size | Factory Delivery Pressure | Adjustment Range | Bonnet Vent Position | Vapor Capacity BTU/hr. Propane** |
| LV4403B4 | ½" F. NPT | ½" | #28 Drill | 11" w.c. at 10 PSIG Inlet |
9" to 13" w.c. | Over Inlet | 935,000 |
| LV4403B46 | ¾" F. NPT | ||||||
| LV4403B46R* | |||||||
| LV4403B66 | ¾" F. NPT | ||||||
| LV4403B66R* |
* Backmount design
** Maximum flow based on 10 PSIG inlet and 9” w.c. delivery pressure.
